Fig. 106: Identifying Cylinders Block 2. INSPECT CYLINDER BORE a. Using a cylinder gauge, measure the cylinder bore diameter at positions A and B in the thrust and axial directions. Standard diameter: 94.000 to 94.012 mm (3.700 to 3.701 in.) Maximum diameter: 94.200 mm (3.709 in.) If the diameter is more than the maximum, replace the cylinder block. Fig. 107: Measuring Cylinder Bore Diameter 3. INSPECT RING GROOVE CLEARANCE a. Using a feeler gauge, measure the clearance between a new piston ring and the wall of the ring groove. Standard ring groove clearance
2009 Toyota Tundra 2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra
|
