e Apply a light coat of engine oil on the threads and under the head of the bolt f Using a wrench to hold the hexagonal portion of the camshaft, install the camshaft timing exhaust Torque: 100 N*m (1020 kgf*cm, 74 ft.*lbf) Fig. 309: Installing Camshaft Timing Exhaust Gear Fig. 307: Identifying Straight Pin And Key Groove Do not loosen or remove the 4 bolts shown in the illustration. If Fig. 308: Identifying Flange Bolt
2009 Toyota Tundra 2009 ENGINE Engine Mechanical (3UR-FE) - Tundra
|
