Fig. 78: Identifying Wire Harness Clamp c Connect the vent line hose 1 Push the hose into the port and push the retainer to lock it Fig. 79: Pushing Hose Into Port And Push Retainer To Lock It d Connect the air inlet line hose e Connect the purge line hose f Connect the pump module connector g Connect the wiring harness clamp bracket with the nut NOTE: Check for damage or foreign objects on the connected After connecting, check that the vent hose and the valve NOTE: Check for damage or foreign objects on the connected part. After connecting, check that the vent hose and the valve are
2009 Toyota Tundra 2009 ENG NE Emission Control (1GR-FE) - Tundra
|
