b. Measure the voltage according to the value (s) in the table below. Standard voltage VOLTAGE SPECIFIED CONDITION NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION SWITCH - OK: Go to Next Step 8. INSPECT IGNITION SWITCH a. Inspect the ignition switch (see INSPECTION ). NG: REPLACE IGNITION SWITCH (See REMOVAL ) OK: Go to Next Step 9. INSPECT PARK/NEUTRAL POSITION SWITCH (POWER SOURCE) a. Disconnect the D35 PNP switch connector. Fig. 330: Identifying D35 PNP Switch Connector Terminals b. Measure the voltage according to the value (s) in the table below. Standard voltage VOLTAGE SPECIFIED CONDITION NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (PNP SWITCH - IGNITION Tester Connection Condition Specified Condition J9-5 (AM2) - Body ground Always 11 to 14 V Tester Connection Condition Specified Condition D35-4 - Body ground While cranking the engine 11 to 14 V
2009 Toyota Tundra 2009 ENGINE PERFORMANCE Engine Control System (3UR-FBE) - Tundra
