Fig. 313: Fuel Injector - Wiring Diagram INSPECTION PROCEDURE 1. CHECK INJECTOR ASSEMBLY (POWER SOURCE) a. Disconnect the injector connector. Fig. 314: Identifying Injector Connector Terminals b. Turn the ignition switch to ON. c. Measure the voltage according to the value (s) in the table below. Standard voltage VOLTAGE SPECIFIED CONDITION Cylinder Tester Connection Switch Condition Specified Condition No. 1 H1 - 2 - Ground Ignition switch ON 11 to 14 V No. 2 F1 - 2 - Ground Ignition switch ON 11 to 14 V No. 3 H2-2 - Ground Ignition switch ON 11 to 14 V No. 4 F2-2 - Ground Ignition switch ON 11 to 14 V No. 5 H3-2 - Ground Ignition switch ON 11 to 14 V No. 6 F3-2 - Ground Ignition switch ON 11 to 14 V No. 7 H4-2 - Ground Ignition switch ON 11 to 14 V
