If the result is not as specified, replace the integration relay. Fig. 380: Identifying Integration Relay Connector Terminals 4. INSTALL INTEGRATION RELAY (UNIT E) a. Connect the 3 connectors. b. Install the integration relay to the engine room relay block. c. Install the engine room relay block cover. 5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL EFI RELAY ON-VEHICLE INSPECTION 1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL 1B-7 NOTE: Some systems need to be initialized after the cable is reconnected (see NOTE: Some systems need to be initialized after the cable is reconnected After the ignition switch is turned OFF, the navigation system
2008 Toyota Tundra 2008 ENGINE PERFORMANCE Engine Control System (1GR-FE) - Tundra
|
