TYPICAL MALFUNCTION THRESHOLDS "Saturated" indicates that the EVAP pressure change is less than 0.286 kPa-g (2.14 mm Hg-g) in 60 seconds. TYPICAL MALFUNCTION THRESHOLDS MONITOR RESULT Refer to CHECKING MONITOR STATUS . DTC P0441 EVAPORATIVE EMISSION CONTROL SYSTEM INCORRECT PURGE FLOW DTC SUMMARY DTC SUMMARY CHART Leak detection pump Not operated by scan tool Both of following conditions met before key off Conditions 1 and 2 1. Duration that vehicle driven 5 minutes or more 2. EVAP purge operation Performed ECT 4.4 to 35°C (40 to 95°F) IAT 4.4 to 35°C (40 to 95°F) One of following conditions met - EVAP pressure just after reference pressure measurement started More than -1 kPa-g (-7.5 mmHg-g) Less than -4.85 kPa-g (-36.4 mmHg-g) Reference pressure -1.057 kPa-g (-7.93 mmHg-g) or more Reference pressure Not saturated within 60 seconds Reference pressure difference between first and second 0.7 kPa-g (5.25 mmHg-g) or more DTC Monitoring Item Malfunction Detection Condition Trouble Area Detection Timing Detection Logic Purge VSV Leak detection pump creates Purge VSV Connector/wire ECM Canister pump While 2 trip Purge VSV After EVAP leak check Purge VSV Connector/wire While 2 trip
2008 Toyota Tundra 2008 ENGINE PERFORMANCE Engine Control System (1GR-FE) - Tundra
|
