RECOMMENDED TOOLS

A750E AUTOMATIC TRANSMISSION - RECOMMENDED TOOLS

EQUIPMENT

A750E AUTOMATIC TRANSMISSION - EQUIPMENT

LUBRICANT

09992-00095

Automatic Transmission Oil Pressure Gauge Set

(09992-00231) Adaptor C

(09992-00271) Gauge Assembly

09031-00030

Pin Punch

09082-00040

TOYOTA Electrical Tester

Angle gauge

Calipers

Cylinder gauge

Dial indicator

Feeler gauge

Micrometer

OBD II scan tool

Straightedge

Torque wrench

V block

Vernier calipers

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra

A750E AUTOMATIC TRANSMISSION - LUBRICANT

SSM

A750E AUTOMATIC TRANSMISSION - SSM

A750F AUTOMATIC TRANSMISSION

SST

A750F AUTOMATIC TRANSMISSION - SST

Automatic transmission fluid: Dry fill

10.4 liters (11.0 US qts, 9.2 lmp.

qts)

Toyota Genuine ATF
WS

Automatic transmission fluid: Drain and
refill

3.0 liters (3.2 US qts, 2.6 lmp. qts)

Toyota Genuine Seal Packing 1281, Three Bond 1281 or equivalent

Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent

09226-10010

Crankshaft Front & Rear Bearing Replacer

09320-89010

Transfer Clutch Spring Compressor

09350-30020

TOYOTA Automatic Transmission Tool Set

(09350-07020) Oil Pump Puller

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra

(09350-07040) No. 2 Piston Spring Compressor

(09350-07050) No. 3 Piston Spring Compressor

(09350-07060) No. 1 Snap Ring Expander

(09350-07070) No. 2 Snap Ring Expander

(09350-07080) Brake Reaction Sleeve Puller

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra

(09350-07090) Brake No.1 Piston Puller

(09350-07110) Oil Seal Replacer

(09351-32140) Oil Seal Replacer

09350-32014

TOYOTA Automatic Transmission Tool Set

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra
