1E-13 Engine Lubrication System: For J20 Engine Diagnostic Information and Procedures Oil Pressure Check S6JB0A1524001 WARNING !
To avoid danger of being burned, do not
NOTE If oil level is low, add oil up to Full level • Oil quality If oil is discolored, or deteriorated, change • Oil leaks If leak is found, repair it.
1) Disconnect oil pressure switch connector. 3) Install special tool (Oil pressure gauge) to vacated threaded hole. Special tool CAUTION !
Be careful not to make special tool touch
4) Start engine and warm it up to normal operating temperature. NOTE
5) After warming up, raise engine speed to 4,000 rpm and measure oil pressure. Oil pressure specification 2 , 55.5 psi) 6) After checking oil pressure, stop engine and remove oil pressure gauge. 7) Before reinstalling oil pressure switch (2), be sure to wrap its screw threads with sealing tape (1) and Tightening torque NOTE
8) Start engine and check oil pressure switch for oil leakage. If oil leakage is found, repair it. 9) Connect oil pressure switch coupler. 1 I5JB0A152001-01 (A) (B) I5JB0A152002-01 1 2 2, (a) I5JB0A152003-01 |
