00-9 Precautions: Precaution for Vehicle Equipped with ESP ® System S6JB0A0000004 • When testing with any of the following equipments (when vehicle is tested by rotating wheels (tires) ® system referring to “Precautions in Speedometer Test ® control module judges that wheels are in slip condition and controls engine torque to ESP ® control module • When ESP ® control module is removed / installed, do not use impact wrenches which generate shock or ® control module. • When any of the following operation is done, calibrate steering angle sensor, G sensor and master cylinder ® control module) referring to “Sensor Calibration in Section 4F”. ® control module is removed. – When yaw rate / G sensor assembly is removed. Precautions for Catalytic Converter (Petrol S6JB0A0000005 For vehicles equipped with a catalytic converter, use make it as short as possible, and do not open the • Conduct engine compression checks within the shortest possible time. • Avoid situations which can result in engine misfire (e.g. starting the engine when the fuel tank is nearly Precautions for Catalytic Converter and Diesel S6JB0A0000017 • Use only specified fuel and be careful not to let a large amount of unburned fuel enter the converter and filter • Be careful not to expose catalytic converter and diesel particulate filter to excessive shock to avoid an Precaution for CAN Communication System S6JB0A0000006 • The loose (1) in the wire harnesses twist of the CAN lines except around the connector (3) should be within • Do not connect terminals of the CAN line using a bypass wire (1). Otherwise, the CAN line may be Precautions for Electrical Circuit Service S6JB0A0000007 • When replacing a fuse, make sure to use a fuse of the specified capacity. Use of a fuse with a larger capacity 2. Controller 3 3 2 2 1 I4JA01000002-01 1 I4JA01000003-01 I2RH01010038-01 |
