6A–85 ENGINE MECHANICAL (6VD1 3.2L) Connecting Rods 1. Check the connecting rod alignment If either the bend or the twist exceeds the specified limit, the connecting Bend per 100 mm (3.937 in) 015RS030 2. Measure the connecting rod thrust clearance. Use a feeler gauge to measure the thrust clearance at the Standard : 0.16 mm–0.35 mm (0.0063 in.–0.0138 in) Limit : 0.40 mm (0.0157 in) 015RS031 3. Measure the oil clearance between the connecting rod and the crankshaft. caps (12). 2. Clean the rod bearings and the crankshaft pins. 3. Carefully check the rod bearings. If even one bearing is found to be damaged or badly worn, the 015RS032 |
