4A1–10 DIFFERENTIAL (FRONT) 11. Remove flange. 12. Remove dust cover. 13. Remove the drive pinion assembly using a soft metal rod and a hammer. 425RS012 14. Remove collapsible spacer. 15. Remove the inner bearing using remover 5–8840– 0015–0 and a press. 415RW033 16. Remove adjust shim. 17. Remove oil seal. 18. Remove outer bearing. 19. Remove the inner bearing outer race (1) and the outer bearing outer race (2) by using a brass bar 425RS014 425RS015 |
