8D–128 WIRING SYSTEM Diagnosis Dome Light Inoperative Step Action Value(s) Yes No 1 Remove the dome light bulb. Is the bulb normal? — Go to Step 2 Replace the bulb 2 1. Reinstall the bulb. Is there continuity between the dome light side — Go to Step 3 Repair or replace the dome light 3 Is the battery voltage applied between harness side Approx. 12V Go to Step 4 Go to Step 5 4 Repair an open circuit between the fuse C–5 and the Is the action complete? — Verify repair — 5 Repair an open circuit between the dome light and the Is the action complete? — Verify repair — |
