8D–52

WIRING SYSTEM

Circuit Diagram–2 (6VD1)

D08RX159

8D–53

WIRING SYSTEM

Circuit Diagram–3 (6VD1 M/T)

D08RX176

8D–54

WIRING SYSTEM

Circuit Diagram–3 (6VD1 A/T)

D08RX160

8D–55

WIRING SYSTEM

Circuit Diagram–4 (6VD1)

D08RX161
