7A–48 AUTOMATIC TRANSMISSION (4L30–E) Speed Sensor (Extension Housing) Removal 1. Disconnect battery ground cable. speed sensor. 4. Remove one 10 mm screw and speed sensor with O-ring. Installation 1. Inspect the speed sensor O-ring, and replace it if necessary. 2. Install speed sensor assembly and 10 mm screw. Torque: 9 N • m (78 lb in) 3. Connect speed sensor harness connector to speed sensor. 4. Connect battery ground cable. Transmission Oil Temperature Sensor (Adapter Case) Removal 1. Raise the vehicle and support it on jack stands. screws, adapter case oil pan, and gasket. NOTE: Oil pan still contains transmission fluid. Place a 5. Disconnect wiring harness from force motor solenoid, converter clutch solenoid, and 5 pin connector of 6. Disconnect ground wire from converter clutch solenoid wiring harness connector. 7. Remove wiring harness assembly (transmission oil temperature sensor). 243RW002 Installation 1. Connect ground wire to converter clutch solenoid wiring harness connector of the wiring harness 2. Install wiring harness assembly to converter clutch solenoid, force motor, and 5 pin connector of adapter 3. Install oil pan gasket, oil pan and twelve 10 mm fixing screws. Tighten the screws to the specified torque. Torque: 11 N • m (96 lb in) 4. Fill transmission through the overfill screw hole of oil pan, using ATF DEXRON –III. Refer to Changing Transmission Fluid in this section. 5. Connect battery ground cable. |
