8A–10

LIGHTING SYSTEM

High Mounted Stoplight Assembly

Removal

1. Disconnect the battery ground cable.

2. Remove the high mount stoplight assembly (2).

• Remove the cover (3).

• Disconnect the connectors (1).

• Remove two screws.

803RX001

Installation

To install, follow the removal steps in the reverse order.

High Mounted Stoplight Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the cover.

3. Remove the bulb (1).

• Remove the socket by turning it

counterclockwise.

825RW071-1

Installation

To install, follow the removal steps in the reverse order.

SECTION

LIGHTING SYSTEM

8A–11

Backup Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the rear combination light assembly.

• Refer to the Taillight Bulb removal step 2 in this

section.

• Remove the bulb (1) by turning it

counterclockwise while pushing it at the same
time.

825RW073

Installation

To install, follow the removal steps in the reverse order.

Front Turn Signal Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the radiator grille.

• Refer to Engine Hood and Fender in section.

3. Remove the front turn signal light (2).

• Remove three screws.

4. Remove the bulb (1).

• Remove the front turn signal light socket by

turning it counterclockwise.

• Remove the bulb by turning it counterclockwise

while pushing it at the same time.

825RW067

Installation

To install, follow the removal steps in the reverse order.

SECTION

8A–12

LIGHTING SYSTEM

Side Turn Signal Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the side turnsignal light assembly.

• Pushing in the rear direction of vehicle, pull out it

toward you.

3. Remove the bulb (1) by turning it counterclockwise.

801RW024

Installation

To install, follow the removal steps in the reverse order.

Rear Turn Signal Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the rear combination light assembly.

• Refer to the Taillight Bulb in this section.

• Remove the bulb (1) by turning it

counterclockwise while pushing it at the same
time.

825RW074

Installation

To install, follow the removal steps in the reverse order.

SECTION

LIGHTING SYSTEM

8A–13

Dome Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the lens (2).

3. Remove the bulb (1).

• Pull out the bulb.

825RW075

Installation

To install, follow the removal steps in the reverse order.

Courtesy Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the lens (2).

3. Remove the bulb (1).

• Pull out the bulb.

825RW076

Installation

To install, follow the removal steps in the reverse order.
