7A–82 AUTOMATIC TRANSMISSION (4L30–E) Disassembly 1. Install the J–23327 compressor tool on spring seat, then compress the spring seat. D Remove retaining ring (1). NOTE: Do not over-stress the springs and seat, as this D Remove the compressor tool. 247RS008 2. Remove spring seat (2) and springs (3). center support (5) from adapter case. 5. Remove gasket transfer plate/outer support (6), center support transfer plate (7), and gasket transfer 6. Remove restrictor (9) from adapter case housing. overrun lock out valve (13) from center support (5). Inspection and Repair Visual Check: If any damage, deformation or wear is found, replace the Reassembly 1. Install overrun lock out valve (13) and spring (12) to center support. NOTE: Ensure correct assembly of valve. The spring 2. Install plug (11) and retainer plate (10). adapter case housing. 242RS005 4. Install gasket transfer plate/adapter case (8), center support transfer plate (7), and gasket transfer 5. Install center support (5) with 8 bolts. Torque : 25 N • m (18 lb ft) 6. Install piston assembly (4) into center support (5). retaining ring (1). D Install the J–23327 compressor and compress D Remove the tool. |
