6A–40 ENGINE MECHANICAL (X22SE 2.2L) 16. Remove transmission mounting fixing bolts and nut from cross member. 022RW014 17. Remove transmission front under cover from front portion of clutch housing. 18. Disconnect two fuel pipes at right side of transmission by quick type fuel hose connector. CAUTION: Plug fuel pipe on engine side and fuel 19. Disconnect canister hose next to fuel piping connector. 20. Remove propeller shaft fixing bolt from rear side transmission. 21. Remove fixing bolts between clutch housing and transmission, then move transmission. 22. Remove power steering pump assembly then place the power steering pump along with piping. 23. Disconnect two chassis harness connectors from right rear side engine compartment (under fuse box) 24. Remove engine ground cable from chassis frame. 25. Remove radiator lower hose from engine side. 26. Remove two heater hoses from right side panel. 27. Remove radiator grille. 28. Remove harness clip from behind right horn. 29. Remove engine mounting bolt from chassis frame side. 022RW005 022RW006 30. Lift up the engine assembly. |
