8D–159
WIRING SYSTEM
Windshield Wiper and Washer
General Description
The system consists of a windshield wiper and washer
switch, alarm & relay control unit, windshield wiper motor
and windshield washer motor. With the starter switch in
the “ON” position, when the windshield wiper switch is
turned on (“ON” or “HI”) the battery voltage is applied to
the windshield wiper motor to operate the wipers.
When the “INT” switch is turned on, the operation of the
wipers is controlled by the alarm & relay control unit.
When the “WASHER” switch is turned on, the operation of
the wipers is also controlled by the alarm & relay control
unit and the windshield washer motor operates to squirt
the washing solution when the washer switch is pressed.
