AV-168

< ON-VEHICLE REPAIR >

[PREMIUM AUDIO (CREW CAB)]

FRONT TWEETER

FRONT TWEETER

Removal and Installation

INFOID:0000000005274978

REMOVAL

CAUTION:

Use a suitable tool to prevent damage to the front tweeter speaker grille trim and the instrument panel.

1.

Remove the front tweeter grille.

2.

Remove the front tweeter screws (A).

3.

Pull out the front tweeter speaker (1) and disconnect front
tweeter connector, then remove the front tweeter speaker (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1074ZZ

AV

FRONT DOOR SPEAKER

AV-169

< ON-VEHICLE REPAIR >

[PREMIUM AUDIO (CREW CAB)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

FRONT DOOR SPEAKER

Removal and Installation

INFOID:0000000005274979

REMOVAL

1.

Remove the front door finisher. Refer to

INT-14, "Removal and Installation"

.

2.

Remove the front door speaker screws (A).

3.

Pull out the front door speaker (1), and disconnect the front door
speaker connector and remove the front door speaker (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0347ZZ

AV-170

< ON-VEHICLE REPAIR >

[PREMIUM AUDIO (CREW CAB)]

REAR DOOR SPEAKER

REAR DOOR SPEAKER

Removal and Installation

INFOID:0000000005274980

REMOVAL

1.

Remove the rear door finisher. Refer to

INT-14, "Removal and Installation"

.

2.

Remove the rear door speaker screws (A).

3.

Disconnect the rear door speaker connector (B) and remove
rear door speaker (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0348ZZ

AV

REAR DOOR TWEETER

AV-171

< ON-VEHICLE REPAIR >

[PREMIUM AUDIO (CREW CAB)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REAR DOOR TWEETER

Removal and Installation

INFOID:0000000005274981

REMOVAL

1.

Remove the rear door finisher. Refer to

INT-14, "Removal and Installation"

.

2.

Remove the rear door tweeter screws (A) and remove the rear
door tweeter (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0351ZZ
