DLK-70 < ECU DIAGNOSIS INFORMATION > BCM (BODY CONTROL MODULE) 32 R/G Combination switch Output ON Lighting, turn, wiper OFF 33 R/Y Combination switch Output ON Lighting, turn, wiper OFF 34 L Combination switch Output ON Lighting, turn, wiper OFF 35 O/B Combination switch Output ON Lighting, turn, wiper OFF 36 R/W Combination switch 37 B/R Key switch and key Input OFF Key inserted Battery voltage Key inserted 0V 38 W/L Ignition switch (ON) Input ON — Battery voltage 39 L CAN-H — — — — 40 P CAN-L — — — — 47 SB Front door switch LH Input OFF ON (open) 0V Rear door switch low- Rear door switch up- OFF (closed) Battery voltage 48 R/Y Rear door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 50 R/Y Cargo bed lamp con- Output OFF Cargo lamp switch (ON) 0V Cargo lamp switch (OFF) Battery voltage Terminal Wire color Signal name Signal input/ output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition SKIA5291E SKIA5292E SKIA5291E SKIA5292E |
