ENGINE OIL LU-9 < PERIODIC MAINTENANCE > C D E F G H I J K L M A LU N P O 3. Disconnect harness connector at oil pressure switch (2), and CAUTION: Never drop or shock oil pressure switch. 4. Install the oil pressure gauge [SST: ST25051001 (J-25695-1)] 5. Start the engine and warm it up to normal operating temperature. 6. Check the engine oil pressure with engine running under no-load. If difference is extreme, check engine oil passage and oil pump for engine oil leakage. 7. After the inspections, install oil pressure switch as follows: a. Remove old liquid gasket adhering to oil pressure switch and the mating surface. b. Apply liquid gasket and tighten oil pressure switch to the specification. GI-22, "Recommended Chemical Prod- . c. After warming up engine, check there is no leakage of engine oil with running engine. Draining INFOID:0000000009648842 WARNING: • Be careful not to get burn yourself, as engine oil may be hot. contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as 1. Warm up the engine, and check for engine oil leakage from engine components. Refer to 2. Stop the engine and wait for 10 minutes. 3. Loosen oil filler cap. 1 : Oil filter : Vehicle front JPBIA1677ZZ JPBIA0074ZZ Engine oil pressure : Refer to Tightening torque : Refer to . |
