Nissan Quest E52. Manual - part 200
BCS
BCM
BCS-43
< ECU DIAGNOSIS INFORMATION >
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
DETE SW -IPDM
Selector lever in any position other than P
Off
Selector lever in P position
On
SFT PN -IPDM
Selector lever in any position other than P and N
Off
Selector lever in P or N position
On
SFT P -MET
Selector lever in any position other than P
Off
Selector lever in P position
On
SFT N -MET
Selector lever in any position other than N
Off
Selector lever in N position
On
ENGINE STATE
Engine stopped
Stop
While the engine stalls
Stall
At engine cranking
Crank
Engine running
Run
S/L LOCK-IPDM
NOTE:
The item is indicated, but not monitored.
Off
S/L UNLK-IPDM
NOTE:
The item is indicated, but not monitored.
Off
S/L RELAY-REQ
NOTE:
The item is indicated, but not monitored.
Off
VEH SPEED 1
While driving
Equivalent to speed-
ometer reading
VEH SPEED 2
While driving
Equivalent to speed-
ometer reading
DOOR STAT-DR
Driver door is locked
LOCK
Wait with selective UNLOCK operation (60 seconds)
READY
Driver door is unlocked
UNLOCK
DOOR STAT-AS
Passenger door is locked
LOCK
Wait with selective UNLOCK operation (60 seconds)
READY
Passenger door is unlocked
UNLOCK
ID OK FLAG
Driver side door is open after ignition switch is turned OFF
(Shift position is in the P position)
Reset
Ignition switch ON
Set
PRMT ENG STRT
The engine start is prohibited
Reset
The engine start is permitted
Set
PRMT RKE STRT
NOTE:
The item is indicated, but not monitored.
Reset
RKE OPE COUN1
During the operation of the key
Operation frequency
of the key
RKE OPE COUN2
NOTE:
The item is indicated, but not monitored.
—
CONFRM ID ALL
The key ID that the key slot receives is not recognized by any key ID reg-
istered to BCM.
Yet
The key ID that the key slot receives is recognized by any key ID regis-
tered to BCM.
Done
CONFIRM ID4
The key ID that the key slot receives is not recognized by the fourth key ID
registered to BCM.
Yet
The key ID that the key slot receives is recognized by the fourth key ID reg-
istered to BCM.
Done
Monitor Item
Condition
Value/Status
