AROUND VIEW MONITOR CONTROL UNIT

AV-495

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

DTC Index

INFOID:0000000009942941

37

(B)

Ground

Front camera
ground

—

Igni-

tion

switch

ON

—

0.1  V  or  less

0  V

38

(R)

37

(B)

Front camera power
supply

Output

Igni-

tion

switch

ON

“CAMERA”
switch (around
view monitor
switch) is ON or
shift position is
“R”.

5.9 - 6.5 V

6.2 V

39

—

Shield

—

—

—

—

—

40

(W)

39

Front camera image
signal

Input

Igni-

tion

switch

ON

“CAMERA”
switch (around
view monitor
switch) is ON or
shift position is
“R”.

Waveform ac-
cording to cam-
era image is
input.

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

JSNIA0834GB

DTC

CONSULT display

Refer to

U0428

ST ANGLE SENSOR CALIBRATION

AV-534, "Diagnosis Procedure"

U1000

CAN COMM CIRCUIT

AV-535, "AROUND VIEW MONI-

TOR CONTROL UNIT :

Diagnosis Procedure"

U1010

CONTROL UNIT (CAN)

AV-537, "AROUND VIEW MONI-

TOR CONTROL UNIT : DTC Log-

ic"

U111A

REAR CAMERA IMAGE SIGNAL

AV-538, "Diagnosis Procedure"

U111B

SIDE CAMERA RH IMAGE SIGNAL

AV-540, "Diagnosis Procedure"

U111C

FRONT CAMERA IMAGE SIGNAL

AV-542, "Diagnosis Procedure"

U111D

SIDE CAMERA LH IMAGE SIGNAL

AV-544, "Diagnosis Procedure"

U1232

ST ANGLE SEN CALIB

AV-568, "AROUND VIEW MONI-

TOR CONTROL UNIT : Diagnosis

Procedure"

U1304

CAMERA IMAGE CALIB

AV-577, "Diagnosis Procedure"

U1305

CONFIG UNFINISH

AV-578, "Diagnosis Procedure"

AV-496

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

BOSE AMP.

BOSE AMP.

Reference Values

INFOID:0000000009652286

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA1223ZZ

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(W)

2

(B)

Sound signal front
squawker LH

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

4

(BR)

3

(Y)

Sound signal front
squawker RH

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

10

(SB)

7

(B)

12

(B)

Battery power sup-
ply

Input

Igni-

tion

switch

OFF

—

9.0 – 16.0 V

Battery power supply

11

(G)

7

(B)

12

(B)

Battery power sup-
ply

Input

Igni-

tion

switch

OFF

—

9.0 – 16.0 V

Battery power supply

13

(R)

8

(G)

Sound signal
woofer

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE AMP.

AV-497

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

14

(L)

9

(P)

Sound signal slide
door speaker RH

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

16

(Y)

17

(BR)

Sound signal lug-
gage squawker

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

18

(BR)

19

(G)

Sound signal front
door woofer LH

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

20

(LG)

7

(B)

12

(B)

Amp. ON signal

Input

Igni-

tion

switch

ACC

—

6.5 V or more

12.0 V

24

(R)

23

(L)

Sound signal rear
LH

Input

Igni-

tion

switch

ON

Sound output

Waveform accord-
ing to sound signal
is input.

26

(BR)

25

(Y)

Sound signal rear
RH

Input

Igni-

tion

switch

ON

Sound output

Waveform accord-
ing to sound signal
is input.

28

(L)

15

(R)

Sound signal slide
door speaker LH

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-498

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

BOSE AMP.

29

(V)

30

(P)

Sound signal cen-
ter squawker

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

31

(L)

32

(R)

Sound signal front
door speaker RH

Output

Igni-

tion

switch

ON

Sound output

Outputs wave-
form synchronized
with sound.

33

(V)

34

(G)

Sound signal front
RH

Input

Igni-

tion

switch

ON

Sound output

Waveform accord-
ing to sound signal
is input.

35

(W)

36

(B)

Sound signal front
LH

Input

Igni-

tion

switch

ON

Sound output

Waveform accord-
ing to sound signal
is input.

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E
