WCS-22 < ECU DIAGNOSIS INFORMATION > COMBINATION METER OIL W/L Ignition switch Oil pressure warning lamp ON On Oil pressure warning lamp OFF Off MIL Ignition switch Malfunction indicator lamp ON On Malfunction indicator lamp OFF Off CRUISE IND Ignition switch CRUISE indicator ON On CRUISE indicator OFF Off SET IND Ignition switch NOTE: Off CRUISE W/L Ignition switch NOTE: Off BA W/L Ignition switch NOTE: Off O/D OFF IND Ignition switch O/D OFF indicator lamp ON On O/D OFF indicator lamp OFF Off 4WD W/L Ignition switch NOTE: Off 4WD LOCK IND Ignition switch NOTE: Off FUEL W/L Ignition switch During low fuel warning indication On Other than the above Off WASHER W/L Ignition switch During low washer fluid warning indication On Other than the above Off AIR PRES W/L Ignition switch Low tire pressure warning lamp ON On Low tire pressure warning lamp OFF Off KEY G/Y W/L Ignition switch During Intelligent Key system malfunction On Other than the above Off EPS W/L Ignition switch EPS warning lamp ON On EPS warning lamp OFF Off AFS OFF IND Ignition switch NOTE: Off ECO MODE IND Ignition switch NOTE: Off Monitor Item Condition Value/Status |
