EM-60 < REMOVAL AND INSTALLATION > CAMSHAFT Valve Lifter Clearance VALVE LIFTER OUTER DIAMETER VALVE LIFTER HOLE DIAMETER VALVE LIFTER CLEARANCE outer diameter) • If out of the standard, referring to the each standard of valve lifter outer diameter and valve lifter hole diameter, replace either or both INSPECTION AFTER INSTALLATION Inspection of Camshaft Sprocket (INT) Oil Groove CAUTION: • Perform this inspection only when DTC P0011 is detected in self-diagnostic results of CONSULT and it is directed according to inspection procedure of EC section. Refer to . • Check when engine is cold so as to prevent burns by the splashing engine oil. 1. Check engine oil level. Refer to . 2. Perform the following procedure so as to prevent the engine from being unintentionally started while a. Release the fuel pressure. Refer to . b. Remove intake manifold. Refer to c. Disconnect ignition coil and injector harness connectors. d. Support the bottom surface of engine using a transmission jack, and then remove the engine mounting 3. Remove intake valve timing control solenoid valve. Refer to • Lift the front side of the engine with a jack base to remove intake valve timing control solenoid valve. 4. Clean the mounting area of intake valve timing control solenoid valve, and then insert a clean waste with 5. Install engine mounting insulator (RH) and engine mounting bracket (RH). (After the removal of intake 6. Perform cranking to check that engine oil comes out from the oil hole (mounting hole of intake valve timing hole. WARNING: • Never insert fingers into the oil hole. Standard : Refer to . PBIC3185J Standard : Refer to Standard : Refer to PBIC3184J |
