SERVICE DATA AND SPECIFICATIONS (SDS)
CL-21
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
E
F
G
H
I
J
K
L
M
A
B
CL
N
O
P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Clutch Control System
INFOID:0000000009949684
Clutch Pedal
INFOID:0000000009949685
Clutch Disc
INFOID:0000000009949686
Clutch Cover
INFOID:0000000009949687
Type of clutch control
Hydraulic
Clutch pedal height “H
1
”
173.6 – 183.6 mm (6.83 – 7.23 in)
Clutch pedal height at clutch disengagement “H
2
”
80 mm (3.15 in) or more
Clutch pedal play “A” [Looseness at clutch pedal pin]
2 – 8 mm (0.08 – 0.31 in) [0 – 1.3 mm (0 – 0.051 in)]
Clearance “C” between stopper rubber and clutch interlock switch
threaded end while clutch pedal is fully depressed.
0.74 – 1.96 mm (0.0291 – 0.0772 in)
Clearance “A” between clutch pedal and ASCD clutch switch
threaded end while clutch pedal is fully released. (With ASCD)
0.74 – 1.96 mm (0.0291 – 0.0772 in)
Facing size (outer dia.
×
inner dia.
×
thickness)
225 mm
×
160 mm
×
3.2 mm
(8.86 in
×
6.30 in
×
0.126 in)
Runout limit/diameter of the area to be measured
1.0 mm (0.039 in) / 215 mm (8.46 in) dia.
Maximum allowable spline backlash (at outer edge of disc)
0.9 mm (0.035 in)
Facing wear limit (depth to the rivet head) “A”
0.3 mm (0.012 in)
Tolerance for diaphragm spring lever unevenness
0.7 mm (0.028 in) or less
