TM-310
< ECU DIAGNOSIS INFORMATION >
[CVT: RE0F11A]
TCM
REVERSE PROHIBIT CONTROL
DTC Inspection Priority Chart
INFOID:0000000009268105
If multiple malfunction codes are detected at the same time, check each code according to the DTC check pri-
ority list below.
Control
The reverse brake is controlled to avoid becoming engaged when the selector lever is set in “R” position while
driving in forward direction at more than the specified speed.
Vehicle behavior in
control
If the selector lever is put at “R” position when driving with the forward gear, the gear becomes neutral, not
reverse.
Normal return condi-
tion
The control returns to normal control when the vehicle is driven at low speeds. (The reverse brake becomes
engaged.)
Priority
DTC (Diagnostic Trouble Code)
Reference
1
P0863 CONTROL UNIT (CAN)
U0073 COMM BUS A OFF
U0100 LOST COMM (ECM A)
U0140 LOST COMM (BCM)
U0141 LOST COMM (BCM A)
U0155 LOST COMM (IPC)
U0300 CAN COMM DATA
U1000 CAN COMM CIRC
U1117 LOST COMM (ABS)
2
P0740 TORQUE CONVERTER
P0743 TORQUE CONVERTER
P0962 PC SOLENOID A
P0963 PC SOLENOID A
P0966 PC SOLENOID B
P0967 PC SOLENOID B
P0998 SHIFT SOLENOID F
P0999 SHIFT SOLENOID F
P099B SHIFT SOLENOID G
P099C SHIFT SOLENOID G
3
P0890 TCM
4
P062F EEPROM
P0705 T/M RANGE SENSOR A
P0706 T/M RANGE SENSOR A
P0711 FLUID TEMP SENSOR A
P0712 FLUID TEMP SENSOR A
P0713 FLUID TEMP SENSOR A
P0715 INPUT SPEED SENSOR A
P0847 FLUID PRESS SEN/SW B
P0848 FLUID PRESS SEN/SW B
P1586 G SENSOR
P1588 G SENSOR
P2765 OUTPUT SPEED SENSOR
5
P0720 OUTPUT SPEED SENSOR
