201
4
QUICK REFERENCE CHART: VERSA SEDAN
Measure value under unladen* conditions.
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Rear Wheel Alignment
INFOID:0000000008955356
Measure value under unladen* conditions.
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Wheelarch Height
INFOID:0000000008955357
Unit: mm (in)
Total toe-in
Distance (A - B)
Minimum
Out 1 mm (0.03 in)
Nominal
In 1 mm (0.05 in)
Maximum
In 3 mm (0.11 in)
Angle
Degree minute second (Decimal
degree)
Minimum
Out 0
° 4′ 48″ (0.08°)
Nominal
In 0
° 4′ 48″ (0.08°)
Maximum
In 0
° 14′ 24″ (0.24°)
Item
Standard
Item
Standard
Camber
Degree minute (Decimal degree)
Minimum
−1° 55′ (−1.91°)
Nominal
−1° 25′ (−1.42°)
Maximum
−0° 55′ (−0.92°)
Total toe-in
Distance (A - B)
Minimum
Out 2.0 mm (0.079 in)
Nominal
In 2.0 mm (0.079 in)
Maximum
In 6.0 mm (0.236 in)
Angle
Degree minute (Decimal degree)
Minimum
Out 0
° 2′ (0.03°)
Nominal
In 0
° 10′ (0.17°)
Maximum
In 0
° 22′ (0.37°)
SEIA0363E
Market
United States
Canada
LEIA0085E
