ECM EC-463 < REMOVAL AND INSTALLATION > [HR16DE] C D E F G H I J K L M A EC N P O REMOVAL AND INSTALLATION ECM Exploded View INFOID:0000000009267332 Removal and Installation INFOID:0000000009267333 CAUTION: Perform ADDITIONAL SERVICE WHEN REPLACING ECM. Refer to . REMOVAL 1. Remove battery. Refer to PG-63, "Removal and Installation" PCS-30, "Removal and Installation" (WITH I-KEY) or (WITHOUT I-KEY). 3. Remove IPDM E/R cover (1). 4. Disconnect ECM harness connectors. INSTALLATION Install in the reverse order of removal. 1. ECM bracket 2. ECM : Vehicle front JSBIA0333ZZ A : mounting nut JSBIA0473ZZ |
