BRM-6

< PRECAUTION >

PRECAUTIONS IN REPAIRING HIGH STRENGTH STEEL

• Follow the specifications for the proper welding pitch.

Unit: mm (in)

Handling of Ultra High Strength Steel Plate Parts

INFOID:0000000009268575

PROHIBITION OF CUT AND CONNECTION

Do not cut and join the lower lock pillar reinforcement (center pillar reinforcement inside frame parts) because

its material is high strength steel plate (ultra high strength steel plate).

The center pillar reinforcement must be replaced if this part is damaged.

Thickness (T)

Minimum pitch (L)

0.6 (0.024)
0.8 (0.031)
1.0 (0.039)
1.2 (0.047)
1.6 (0.063)
1.8 (0.071)

10 (0.39) or over
12 (0.47) or over
18 (0.71) or over
20 (0.79) or over
27 (1.06) or over
31 (1.22) or over

JSKIA0781ZZ

HANDLING PRECAUTIONS FOR PLASTICS

BRM-7

< PRECAUTION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

HANDLING PRECAUTIONS FOR PLASTICS

Precautions For Plastics

INFOID:0000000009268601

1. When repairing and painting a portion of the body adjacent to plastic parts, consider their characteristics

(influence of heat and solvent) and remove them if necessary or take suitable measures to protect them.

2. Plastic parts should be repaired and painted using methods suiting the materials

,

 characteristics.

LOCATION OF PLASTIC PARTS

Abbre-

viation

Material name

Heat resisting

temperature

°C(°F)

Resistance to gasoline and

solvents

Other cautions

PE

Polyethylene

60(140)

Gasoline and most solvents are
harmless if applied for a very
short time (wipe up quickly).

Flammable

PVC

Poly Vinyl Chloride

80(176)

Same as above.

Poison gas is emitted
when burned.

EPM/
EPDM

Ethylene Propylene (Diene) co-
polymer

80(176)

Same as above.

Flammable

PP

Polypropylene

90(194)

Same as above.

Flammable, avoid bat-
tery acid.

UP

Unsaturated Polyester

90(194)

Same as above.

Flammable

PS

Polystyrene

80(176)

Avoid solvents.

Flammable

ABS

Acrylonitrile Butadiene Styrene

80(176)

Avoid gasoline and solvents.

PMMA

Poly Methyl Methacrylate

85(185)

Same as above.

EVAC

Ethylene Vinyl Acetate

90(194)

Same as above.

ASA

Acrylonitrile Styrene Acrylate

100(222)

Same as above.

Flammable

PPE

Poly Phenylene Ether

110(230)

Same as above.

PC

Polycarbonate

120(248)

Same as above.

PAR

Polyarylate

180(356)

Same as above.

PUR

Polyurethane

90(194)

Same as above.

POM

Poly Oxymethylene

120(248)

Same as above.

Avoid battery acid.

PBT+
PC

Poly Butylene Terephthalate +
Polycarbonate

120(248)

Same as above.

Flammable

PA

Polyamide

140(284)

Same as above.

Avoid immersing in wa-
ter.

PBT

Poly Butylene Terephthalate

140(284)

Same as above.

PET

Polyester

180(356)

Same as above.

PEI

Polyetherimide

200(392)

Same as above.

BRM-8

< PRECAUTION >

HANDLING PRECAUTIONS FOR PLASTICS

Item

Component

Abbreviation

Material

1.

Door Mirror

Case

ASA

Acronitrile Styrene Acrylate

Skull cap

ABS

Acronitrile Butadiene Acrylate

2.

Outside door handle

Grip

PC

Polycarbonate

Escutcheon

PA

Polyamide (Nylon)

ALKIA2671ZZ

HANDLING PRECAUTIONS FOR PLASTICS

BRM-9

< PRECAUTION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

3.

Front combination lamp

Lens

PC

Polycarbonate

Housing

PP

Polypropylene

4.

Front bumper fascia

PP + EPM

Polypropylene + Ethylene Propylene (Diene)
copolymer

5.

Rear combination lamp

Lens

PMMA

Poly Methyl Methacrylate

Housing

ABS

Acronitrile Butadiene Acrylate

6.

Rear bumper fascia

PP + EPM

Polypropylene + Ethylene Propylene (Diene)
copolymer

7.

Trunk lid finisher

ABS + PC

Acronitrile Butadiene Acrylate + Polycarbon-
ate

Item

Component

Abbreviation

Material

Item

Component

Abbreviation

Material

1.

Center pillar trim

PP

Polypropylene

2.

Upper quarter trim

PP

Polycarbonate

3.

Rear inner kicking plate

PP

Polypropylene

4.

Front inner kicking plate

PP

Polypropylene

5.

Center console side finishers

PP

Polypropylene

6.

Glove box

PP

Polypropylene

7.

Steering column covers

PP

Polypropylene

8.

Front pillar garnish

PP

Polypropylene

ALKIA2670ZZ
