SYSTEM BRC-21 < SYSTEM DESCRIPTION > [VDC/TCS/ABS] C D E G H I J K L M A B BRC N O P reservoir. The amount of brake fluid supplied to the rear LH wheel cylinder from the master cylinder is con- trolled according to time that the ABS IN valve is not energized (time that the ABS IN valve is open). Brake Release Front RH brake caliper • Brake fluid is supplied to the front RH brake caliper through the return check valve of the ABS IN valve and the cut valve 1, and returns to the master cylinder. Front LH brake caliper • Brake fluid is supplied to the front LH brake caliper through the return check valve of the ABS IN valve and the cut valve 2, and returns to the master cylinder. Rear RH wheel cylinder • Brake fluid is supplied to the rear RH wheel cylinder through the return check valve of the ABS IN valve and the cut valve 2, and returns to the master cylinder. Rear LH wheel cylinder • Brake fluid is supplied to the rear LH wheel cylinder through the return check valve of the ABS IN valve and the cut valve 1, and returns to the master cylinder. Component Parts and Function JSFIA0682GB Name Not activated During brake release Cut valve 1 Power supply is not supplied (open) Power supply is not supplied (open) Cut valve 2 Power supply is not supplied (open) Power supply is not supplied (open) Suction valve 1 Power supply is not supplied (close) Power supply is not supplied (close) Suction valve 2 Power supply is not supplied (close) Power supply is not supplied (close) ABS IN valve Power supply is not supplied (open) Power supply is not supplied (open) ABS OUT valve Power supply is not supplied (close) Power supply is not supplied (close) Each brake caliper and each wheel cylinder — Pressure decreases |
