AV-44

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

AUDIO UNIT

11

(O)

12

(V)

Sound signal front speaker
RH

Output

ON

Sound output

13

 (L)

14

 (Y)

Sound signal rear speaker
RH

Output

ON

Sound output

16

(V)

15

(GR)

Steering switch signal B

Input

ON

Press

switch

0V

Press

switch

1.0V

Press

switch

2.0V

Except above

5.0V

18

(P)

Ground Vehicle speed signal

Input

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH).

19

(Y)

Ground

Battery power supply

Input

–

–

Battery voltage

22

(B/W)

Ground EQ2 Ground

—

ON

–

0 V

23

(B)

Ground EQ3 Ground

—

ON

–

0 V

24

(B)

Ground EQ4 Ground

—

ON

–

0 V

27

(SB)

—

AV communication (H)

Input/

Output

—

—

—

28

(LG)

—

AV communication (L)

Input/

Output

—

—

—

29

(P)

Ground TEL ON

Output

ON

—

—

30

(Shield)

—

TEL voice signal shield

—

—

—

—

Terminal

 (Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIA0177E

SKIA0177E

JSNIA0012GB

AV

AUDIO UNIT

AV-45

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

32

(G)

31

(R)

TEL voice signal

Input

ON

During voice guide output
with

switch

pressed.

37

(B)

Ground Antenna amp. ON signal

Output

ON

Audio unit ON, AM or FM
selected.

Battery voltage

38

(B)

Ground AM/FM antenna signal

Input

ON

Audio unit ON, AM or FM
selected.

5.0 V

Terminal

 (Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIB3609E

AV-46

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

BLUETOOTH® CONTROL UNIT

BLUETOOTH® CONTROL UNIT

Reference Value

INFOID:0000000009375109

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA2819ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

1

 (Y)

Ground Battery power supply

Input

–

–

Battery voltage

2

 (L)

Ground ACC power supply

Input

ACC

or

ON

–

Battery voltage

3

(O)

Ground  Ignition signal

Input

ON

or

START

–

Battery voltage

4

(B)

Ground Ground

–

–

–

0 V

7

(BR)

8

(Shield)

Mic-in signal

Input

ACC

or

ON

While speaking into micro-
phone

9

 (R)

10

 (L)

Audio out

Output

ACC

or

ON

Bluetooth

®

 control unit

sends audio signal

11

(SB)

–

Mute

Output

–

–

–

12

 (W)

Ground Ladder input 1

Input

ACC

or

ON

Press SOURCE switch

0 V

Press

switch

0.7 V

Press

switch

1.3 V

Press

switch

2.0 V

Except for above

3.3 V

PKIB5037J

SKIB3609E

AV

BLUETOOTH® CONTROL UNIT

AV-47

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

13

 (P)

Ground Ladder input 2

Input

ACC

or

ON

Press

switch

 0.7 V

Press

switch

1.3 V

Press

switch

2.0 V

Except for above

3.3 V

14

(G)

-

Ladder ground

Input

-

-

-

17

(BR)

Ground Steering switch signal A

Output

ACC

or

ON

Press SOURCE switch

0 V

Press

switch

0.7 V

Press

switch

1.3 V

Press

switch

2.0 V

Except for above

3.3 V

18

(V)

Ground Steering switch signal B

Output

ACC

or

ON

Press

switch

0.7 V

Press

switch

1.3 V

Press

switch

2.0 V

Except for above

3.3 V

19

 (GR)

–

Steering switch ground

Output

–

–

–

27

 (B)

–

Ground

–

–

–

0 V

28

 (LG)

–

Vehicle speed signal (8-
pulse)

Input

ON

When vehicle speed is ap-
prox. 25 MPH (40 km/h)

29

(Y)

Ground Microphone power

Output

ACC

or

ON

–

5  V

33

(B)

–

Bluetooth

®

 antenna

–

–

–

–

34

(Shield)

–

Bluetooth

®

 antenna shield

–

–

–

–

35

(SB)

–

AV communication (H)

–

–

–

–

36

(LG)

–

AV communication (L)

–

–

–

–

39

(LG)

–

AV communication (H)
jumper

–

–

–

–

40

(LG)

–

AV communication (H)
jumper

–

–

–

–

41

(SB)

–

AV communication (L)
jumper

–

–

–

–

42

(SB)

–

AV communication (L)
jumper

–

–

–

–

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

PKIA1935E
