DLN-32
< BASIC INSPECTION >
[TRANSFER: TY21C]
DIAGNOSIS AND REPAIR WORK FLOW
YES
>> GO TO 7.
NO
>> Check harness and connectors based on the information obtained by interview. Refer to
.
7.
FINAL CHECK
With CONSULT
1. Check the reference value for AWD control unit.
2. Recheck the symptom and check that symptom is not reproduced on the same conditions.
Is the symptom reproduced?
YES
>> GO TO 3.
NO
>> Inspection End.
Diagnostic Work Sheet
INFOID:0000000011278311
Description
• In general, customers have their own criteria for a problem. Therefore, it is important to understand the
symptom and status well enough by asking the customer about his/her concerns carefully. To systemize all
the information for the diagnosis, prepare the interview sheet referring to the interview points.
• In some cases, multiple conditions that appear simultaneously may cause a DTC to be detected.
Interview sheet sample
Interview sheet
Customer
name
MR/MS
Registration
number
Initial year
registration
Vehicle type
VIN
Storage date
Engine
Mileage
km (Mile)
Symptom
Vehicle does not enter AWD mode.
AWD warning (AWD Error) is displayed.
Heavy tight-corner braking symptom occurs
Noise
Vibration
Others
(
)
First occurrence
Recently
Others (
)
Frequency of occurrence
Always
Under a certain conditions of
Sometimes (time(s)/day)
Climate con-
ditions
Irrelevant
Weather
Fine
Cloud
Rain
Snow
Others (
)
Temperature
Hot
Warm
Cool
Cold
Temperature (Approx.
°C)
Relative humidity
High
Moderate
Low
Road conditions
Urban area
Suburb area
High way
Mounting road (uphill or down hill)
Rough road
Operation conditions, etc.
Irrelevant
When engine starts
During idling
During driving
During acceleration
At constant speed driving
During deceleration
During cornering (right curve or left curve)
