BODY ALIGNMENT

BRM-49

< SERVICE DATA AND SPECIFICATIONS (SDS)

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Unit: mm (in)

Passenger Compartment

INFOID:0000000011280099

MEASUREMENT

Dimensions marked with

″*″ indicate symmetrically identical dimensions on both the right and left hand of the

vehicle.

Points

Coordinates

Remarks

X

Y

Z

A

-566

-478

375

Hole

φ18 (0.71)

a

-566

501

375

Hole

φ18 (0.71)

B

-346

-462

502

Hole

φ16 (0.63)

b

-372

474

502

Hole

φ16 (0.63)

C, c

740

±598

911

Hole

φ33 (1.30)

D, d

547

±410

190

Hole

φ20x16 (0.79x0.63)

E, e

1270

±410

189

Hole

φ12 (0.47)

F, f

1751

±410

180

Hole

φ13 (0.51)

G, g

1954

±650

272

Hole

φ16 (0.63)

H, h

2480

±525

380

Hole

φ12 (0.51)

J, j

2622

±523

418

Hole

φ09 (0.35)

K

2911

-549

435

Hole

φ09 (0.35)

k

2897

525

435

Hole

φ09 (0.35)

M

3248

-551

433

Hole

φ20x14 (0.79x0.55)

m

3248

523

433

Hole

φ20x14 (0.79x0.55)

AWKIA2814ZZ

BRM-50

< SERVICE DATA AND SPECIFICATIONS (SDS)

BODY ALIGNMENT

Unit: mm (in)

MEASUREMENT POINTS

Point

Dimension

Point

Dimension

Point

Dimension

Point

Dimension

A - C

700 (27.56)*

F - Q

1172 (46.15)*

K - M

285 (11.25)*

S - U

847 (33.36)*

B - D

582 922.94)*

G - P

1137 (44.77)*

M - F

1229 (48.40)*

U - N

863 (33.99)*

E - J

849 (33.44)*

G - Q

1235 (48.63)*

N - S

281 (11.08)*

U - V

297 (11.70)*

E - K

669 (26.37)*

J - E

849 (33.44)*

N - U

863 (33.99)*

V - S

820 (32.30)*

E - M

678 (26.72)

J - F

850 (33.46)*

S - N

281 (11.08)*

V - N

738 (29.06)*

F - P

1175 (46.28)*

K - J

443 (17.44)*

S - T

712 (28.06)*

Front

ALKIA3285ZZ

BODY ALIGNMENT

BRM-51

< SERVICE DATA AND SPECIFICATIONS (SDS)

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Unit: mm (in)

Rear Body

INFOID:0000000011280100

MEASUREMENT

Dimensions marked with

″*″ indicate symmetrically identical dimensions on both the right and left hand of the

vehicle.

Unit: mm (in)

MEASUREMENT POINTS

Point

Material

Point

Material

A

Center cowl top positioning mark of center posi-
tioning mark

J,,j, K,k, M,m,
N,n, S,s, R,r

Center pillar indent

B

Roof flange end of center positioning mark

T,t U,u V,v

Rear fender indent

C, c

Front pillar joggle

F,f, G,g, Q, q,
P, P

Door hinge installing hole center


φ12 (0.47)

W, w:

φ9 (0.35)

 E, e, H, h, G, g Front pillar indent

AWKIA2815ZZ

BRM-52

< SERVICE DATA AND SPECIFICATIONS (SDS)

BODY ALIGNMENT

Unit: mm (in)

Front

AWKIA2868ZZ

Point

Material

Point

Material

A

Roof flange end of center positioning mark

C, c, D, d

Rear flange jog corner

B, b

Rear flange jog corner

E

Rear panel upper flange end
