PREPARATION

RAX-11

< PREPARATION >

[AWD]

C

E

F

G

H

I

J

K

L

M

A

B

RAX

N

O

P

PREPARATION

PREPARATION

Special Service Tool

INFOID:0000000011280320

The actual shape of the tools may differ from those illustrated here.

Commercial Service Tool

INFOID:0000000011280321

Tool number
(TechMate No.)
Tool name

Description

KV38100500
(

—

)

Drift

Installing sensor rotor
a: 80 mm (3.15 in) dia.
b: 60 mm (2.36 in) dia.

KV40101840
(

—

)

Collar

Installing sensor rotor
a: 67 mm (2.64 in) dia.
b: 85 mm (3.35 in) dia.

ZZA0701D

ZZA1113D

Tool name

Description

Ball joint remover

Removing wheel stud

Power tools

Loosening nuts, screws, and bolts

Drive shaft puller

Removing drive shaft joint sub assembly

NT146

PIIB1407E

JPDIG0152ZZ

RAX-12

< PREPARATION >

[AWD]

PREPARATION

Sliding hammer

Removing drive shaft

Replacer

Removing sensor rotor

Puller

Removing sensor rotor

ZZA0023D

ZZA0700D

ZZA0119D

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

RAX-13

< SYMPTOM DIAGNOSIS >

[AWD]

C

E

F

G

H

I

J

K

L

M

A

B

RAX

N

O

P

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000011280322

Use chart below to find the cause of the symptom. If necessary, repair or replace these parts.

×: Applicable

Reference

—

RAX

-21

—

RAX

-14

—

DLN-98

DLN-1

11

RSU-4

—

WT

-62

WT

-62

DLN-98

BR-6

Possible cause and SUSPECTED PARTS

Ex

ce

ss

iv

e j

oi

nt a

ng

le

Jo

in

t s

lid

in

g re

si

st

an

ce

Im

ba

lan

ce

Im

pro

pe

r in

st

a

lla

tion

, lo

os

en

es

s

Part

s int

erference

PROPELLER SHAF

T

DIFFE

RENTIAL

REAR SUSP

ENSION

REAR AXLE

TIRE

WHEEL

D

R

IV

E

 SH

AF

T

BRAKE

Symptom

DRIVE
SHAFT

Noise

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

REAR AXLE

Noise

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

Vibration

×

×

×

×

×

×

Shimmy

×

×

×

×

×

×

Shudder

×

×

×

×

×

Poor quality ride or handling

×

×

×

×

×

RAX-14

< PERIODIC MAINTENANCE >

[AWD]

REAR WHEEL HUB AND HOUSING

PERIODIC MAINTENANCE

REAR WHEEL HUB AND HOUSING

Inspection

INFOID:0000000011280323

INSPECTION

Make sure the conditions (looseness, back lash) of each component and component conditions (wear, dam-

age) are normal.

WHEEL HUB AND BEARING INSPECTION

• Move wheel hub and bearing in the axial direction by hand. Make sure there is no looseness of wheel bear-

ing.

• Rotate wheel hub, and make sure there is no unusual noise or other irregular conditions. If there is any of

irregular conditions, replace wheel hub and bearing.

Axial end play

: Refer to

RAX-27, "Wheel Bearing"

.
