AV-236 < SYSTEM DESCRIPTION > [NAVIGATION WITH BOSE] DIAGNOSIS SYSTEM (AROUND VIEW MONITOR CONTROL UNIT) CONFIGURATION AV-281, "CONFIGURATION (AROUND VIEW MONITOR CONTROL UNIT) : Description" CAN DIAG SUPPORT MNTR LAN-14, "CAN Diagnostic Support Monitor" . WITH DRIVER ASSISTANCE SYSTEM INFOID:0000000011276929 CONSULT FUNCTIONS CONSULT performs the following functions via communication with the around view monitor control unit: ECU IDENTIFICATION The part number of around view monitor control unit is displayed. SELF DIAGNOSTIC RESULT AV-252, "WITH DRIVER ASSISTANCE SYSTEM : DTC Index" . DATA MONITOR CALIBRATING CAMERA IMAGE STATUS Performs calibration of front camera. AXIS X AXIS Y ROTATE CALIBRATING CAMERA IMAGE STATUS Performs calibration of passenger side camera. AXIS X AXIS Y ROTATE CALIBRATING CAMERA IMAGE STATUS Performs calibration of driver side camera. AXIS X AXIS Y ROTATE CALIBRATING CAMERA IMAGE STATUS Performs calibration of rear camera. AXIS X AXIS Y ROTATE FINE TUNING OF BIRDS-EYE VIEW STATUS Confirmation and adjustment of difference between each camera can be per- SELECT AXIS X AXIS Y ROTATE Support Item Setting Description Direct Diagnostic Mode Description Ecu Identification The around view monitor control unit part number is displayed. Self Diagnostic Result The around view monitor control unit self diagnostic results are displayed. Data Monitor The around view monitor control unit input/output data is displayed in real time. Work support The settings for around view monitor control unit functions can be changed. Configuration • The vehicle specification can be read and saved. CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed. |
