ON-VEHICLE REPAIR

HORN

Removal and Installation

INFOID:0000000004216540

REMOVAL

1. Position aside the front fender protector LH. Refer to

EXT-18, "Removal and Installation"

.

2. Disconnect the horn connectors (A).
3. Remove the horn bracket bolt (B), and remove horn (2) and horn

(1).

INSTALLATION

Installation is in the reverse order of removal.

ALLIA0024ZZ
