GW-22

< REMOVAL AND INSTALLATION >

REAR REGULATOR

4. Remove bolts (A) and the rear door glass rear run channel (1).

5. Temporarily reconnect the rear power window switch to raise/

lower the rear door glass until the rear door regulator to glass

bolts (A) can be seen through the access holes.

6. Remove the rear door regulator to glass bolts (A).

7. Raise up the rear door glass and hold with a suction lifter (A).

8. Disconnect the harness connector from the rear door glass regulator.
9. Remove nuts/bolts (

) and the rear door glass regulator (1).

INSPECTION AFTER REMOVAL

Check the rear door glass regulator for the following items. If a malfunction is detected, replace or grease it.

• Gear wear

• Regulator deformation

• Grease condition for each sliding part

• Apply multi-purpose grease at sliding points.

INSTALLATION

Installation is in the reverse order of removal.

ALKIA2636ZZ

ALKIA2635ZZ

PIIB3511J

ALKIA2637ZZ

REAR POWER WINDOW MOTOR

GW-23

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

REAR POWER WINDOW MOTOR

Removal and Installation

INFOID:0000000009758195

REMOVAL

1. Remove the rear door glass regulator (1). Refer to

GW-21,

"Removal and Installation"

2. Remove the screws and the rear power window motor (2).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA2815ZZ

GW-24

< REMOVAL AND INSTALLATION >

SIDE WINDOW GLASS

SIDE WINDOW GLASS

Components

INFOID:0000000009758196

Removal and Installation

INFOID:0000000009758197

REMOVAL

1. Remove the rear pillar finisher. Refer to

INT-29, "REAR PILLAR FINISHER : Removal and Installation"

.

ALKIA2818ZZ

1.

Side window glass

2.

Spacer

3.

Headlining

4.

Rear body pillar

5.

Rear pillar finisher

6.

Rear door weatherstrip

A. Primer area

B. Adhesive

C. 7 mm (0.3 in)

D. 12 mm (0.5 in)

SIDE WINDOW GLASS

GW-25

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

2. After removing moldings, remove the glass using piano wire or power cutting tool (A) and an inflatable

pump (B).

• Apply protective tape around the windshield glass to protect the painted surface from damage.

• If the windshield glass is to be reused, mark the body and the glass with matching marks.

• Minimum adhesive coating amount 8 +3,-0 g/100 mm (0.28 +0.11,-0 oz/3.9 in) all around.

• Minimum primer application area 20.0 mm (0.79 in) on body and glass side.

WARNING:

When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help pre-

vent glass splinters from entering your eyes or cutting your hands.

CAUTION:

• Be careful not to scratch the glass when removing.

• Do not set or stand the glass on its edge. Small chips may develop into cracks.

• Apply protective tape around the windshield glass to protect the painted surface from damage.

INSTALLATION

Installation is in the reverse order of removal.

• If repainting near the rear window glass flange area, protect the flange adhesion area by masking the flange.

• Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-

nished with it.

• Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within

five minutes after applying the adhesive.

• The start and finish of the urethane adhesive application should be located at the bottom to assure water-

tightness.

• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out

by passenger compartment air pressure when a door is closed.

• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (preferably 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.

• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid

contact with the skin and eyes.

• Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled.

If affected by vapor inhalation, immediately move to an area with fresh air.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the side window glass in case of an accident.

CAUTION:

• Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed

on the box or product.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.

• Do not leave primers or adhesive cartridge unattended with their caps open or off.

• The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely

cured. Curing time varies depending on temperature and humidity. The curing time will increase

under lower temperature and lower humidity.

REPAIRING WATER LEAKS FOR SIDE WINDOW GLASS

• Leaks can be repaired without removing and reinstalling glass.

• If water is leaking between the urethane adhesive material and body or glass, determine the extent of leak-

age.

• This can be done by applying water to the side window area while pushing glass outward.

• To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.
