INTELLIGENT KEY WARNING BUZZER

DLK-107

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

INTELLIGENT KEY WARNING BUZZER

Component Function Check

INFOID:0000000010119790

1.

CHECK FUNCTION

1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.

2. Select “OUTSIDE BUZZER” in “Active Test”.

3. Touch “ON” to check that it works normally.
Is the inspection result normal?

YES

>> Intelligent Key warning buzzer is OK.

NO

>> Refer to

DLK-107, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000010119791

Regarding Wiring Diagram information, refer to

DLK-44, "Wiring Diagram"

.

1.

CHECK FUSE

1. Turn power switch OFF.

2. Check 10 A fuse, [No. 13, located in fuse block (J/B)].
Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Replace the blown fuse after repairing the affected circuit.

2.

CHECK INTELLIGENT KEY WARNING BUZZER POWER SUPPLY CIRCUIT

1. Disconnect Intelligent Key warning buzzer connector.

2. Check voltage between Intelligent Key warning buzzer harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace harness.

3.

CHECK INTELLIGENT KEY WARNING BUZZER CIRCUIT

1. Disconnect BCM connector.

2. Check continuity between BCM harness connector and Intelligent Key warning buzzer harness connector.

3. Check continuity between BCM harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace harness.

4.

CHECK INTELLIGENT KEY WARNING BUZZER

(+)

(–)

Voltage

(Approx.)

Intelligent Key warning buzzer

Connector

Terminal

E28

1

Ground

Battery voltage

BCM

Intelligent Key warning buzzer

Continuity

Connector

Terminal

Connector

Terminal

M23

93

E28

3

Yes

BCM

Ground

Continuity

Connector

Terminal

M23

93

No

DLK-108

< DTC/CIRCUIT DIAGNOSIS >

INTELLIGENT KEY WARNING BUZZER

Refer to

DLK-108, "Component Inspection"

.

Is the inspection result normal?

YES

>> Replace BCM. Refer to

BCS-72, "Removal and Installation"

.

NO

>> Replace Intelligent Key warning buzzer. Refer to

DLK-208, "Removal and Installation"

.

Component Inspection

INFOID:0000000010119792

1.

CHECK INTELLIGENT KEY WARNING BUZZER

1. Turn power switch OFF.

2. Disconnect Intelligent Key warning buzzer connector.

3. Connect battery power supply directly to Intelligent Key warning buzzer terminals and check the opera-

tion.

Is the inspection result normal?

YES

>> Inspection End.

NO

>> Replace Intelligent Key warning buzzer. Refer to

DLK-208, "Removal and Installation"

.

Intelligent Key warning buzzer

Operation

Terminal

(+)

(

−)

1

3

Buzzer sounds

REMOTE KEYLESS ENTRY RECEIVER

DLK-109
