AV DIAGNOSIS SYSTEM (AV CONTROL UNIT) AV-243 < SYSTEM DESCRIPTION > [NAVIGATION WITHOUT BOSE] C D E F G H I J K L M B A O P Navigation STEERING ANGLE ADJUSTMENT • The steering angle output value detected with the gyroscope is adjusted. SPEED CALIBRATION • During normal driving, distance error caused by tire wear and tire pressure change is automatically adjusted for by the automatic dis- tance correction function. This function, on the other hand, is for immediate adjustment, in cases such as driving with tire chain fit- ted on tires. SENSOR INFORMATION • Displays the reception status of the GPS antenna connector. XM SUBSCRIPTION STATUS • The XM subscription status can be checked. Error location display The self-diagnosis results are judged depending on whether any error occurs from when “Self-diagnosis” is selected until the self-diagnosis results are displayed. Diagnosis item Display Vehicle status Remarks Vehicle speed ON Vehicle speed > 0 km/h (0 MPH) Changes in indication may be delayed. This is normal. OFF Vehicle speed = 0 km/h (0 MPH) Parking brake ON Parking brake is applied. OFF Parking brake is released. Lights ON Block the light beam from the auto — OFF Either of the following conditions sor to light when the light switch Power button ON Power button ON — OFF Power button in ACC position Reverse ON Shift the selector lever to “R” posi- Changes in indication may be delayed. This is normal. OFF Shift the selector lever other than JSNIA3765ZZ JSNIA3766ZZ |
