IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) WW-77 < ECU DIAGNOSIS > C D E F G H I J K M A B WW N O P ST/INHI RLY Ignition switch ON Off At engine cranking INHI → ST The status of starter relay or starter control relay cannot be recognized by UNKWN DETENT SW Ignition switch ON • Press the selector button with se- lector lever in P position • Selector lever in any position oth- er than P Off Release the selector button with selector lever in P position On S/L RLY -REQ None of the conditions below are present Off • Open the driver door after the ignition switch is turned OFF (for a few seconds) • Press the push-button ignition switch when the steering lock is activat- ed On S/L STATE Steering lock is activated LOCK Steering lock is deactivated UNLOCK [DTC: B210A] is detected UNKWN DTRL REQ NOTE: Off OIL P SW Ignition switch OFF, ACC or engine running Open Ignition switch ON Close HOOD SW Close the hood Off Open the hood On HL WASHER REQ Not operating Off Headlamp washer operating On THFT HRN REQ Not operating Off Horn is activated with vehicle security (theft warning) system On HORN CHIRP Not operating Off • Door locking with Intelligent Key (horn chirp mode) On CRNRNG LMP REQ NOTE: Off Monitor Item Condition Value/Status |
