ST-34 < REMOVAL AND INSTALLATION > STEERING GEAR AND LINKAGE 12. Apply recommended thread locking sealant to the thread (2 turns thread), and then screw in the adjusting screw until it GI-18, "Recommended Chemical Products and 13. Move rack assembly 10 strokes throughout the full stroke so that the parts can fit with each other. 14. Adjust pinion rotating torque with the following procedure. Measure pinion rotating torque within ± 180 ° of neutral position of the rack assembly using Tools. Stop the gear at the point b. Loosen adjusting screw and retighten to 5.4 N·m (0.55 kg-m, 48 ° . c. Measure pinion rotating torque using Tools to make sure that the d. Apply recommended liquid gasket to inner socket and turn pinion fully to left with inner socket installed to e. Install dial gauge at 5 mm (0.20 in) (L) from the edge of gear f. Measure vertical movement of rack assembly when pinion is • If reading is outside of the specification, readjust screw angle with adjusting screw. CAUTION: • If reading is still outside of specification, or if the rotating torque of adjusting screw is less than 5 N·m (0.51 kg-m, 44 in-lb), replace steering gear assembly. • Never turn adjusting screw more than twice. SGIA0624E A: Preload gauge [SST: ST3127S000 (J-25765-A)] B: Preload adapter [SST: KV48103400 ( — )] SGIA1383E Pinion rotating torque Around neutral position ± 100 ° ) average (A) : 1.59 – 2.0 N·m (0.17 – Maximum variation (B) : 0.39 N·m (0.04 kg-m, 3.0 Vertical movement : 0.265 mm (0.0104 in) SGIA0936E JSGIA0104ZZ |
