BCM (BODY CONTROL MODULE) SEC-171 < ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B SEC N O P 139 (O) Ground Tire pressure receiv- Input/ Output Ignition switch Standby state When receiving the signal 140 (GR) Ground Selector lever P/N Input Selector lever P or N position Battery voltage Except P and N positions 0 V 141 (O) Ground Security indicator Output Security indicator ON 0 V Blinking 11.3 V OFF Battery voltage 142 (L) Ground Combination switch Output Combination All switches OFF 0 V Lighting switch 1ST 10.7 V Lighting switch HI Lighting switch 2ND Turn signal switch RH 143 Ground Combination switch Output Combination All switches OFF 0 V Front wiper switch HI 10.7 V Rear wiper switch INT Any of the conditions below Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – OCC3881D OCC3880D JPMIA0014GB JPMIA0031GB JPMIA0032GB |
