EC-482 < ECU DIAGNOSIS INFORMATION > [VQ35DE] ECM 47 (G) 36 (B) Sensor power supply — [Ignition switch: ON] 5 V 48 (B/P) — Sensor ground — — — 49 (L) 112 (B) A/F sensor 1 (bank 1) Input [Engine is running] 1.8 V 50 (L/Y) 56 (G/B) Intake air temperature sensor Input [Engine is running] 0 - 4.8 V 51 (R/Y) 44 (G/B) Sensor power supply — [Ignition switch: ON] 5 V 52 (B/R) — Sensor ground — — — 53 (V) 57 (LG) A/F sensor 1 (bank 2) Input [Ignition switch: ON] 2.2 V 54 (G) 52 (B/R) Engine oil temperature sensor Input [Engine is running] 0 - 4.8 V 55 (SB) 48 (Y) Sensor power supply — [Ignition switch: ON] 5 V 56 (G/B) — Sensor ground — — — 57 (LG) 112 (B) A/F sensor 1 (bank 2) Input [Engine is running] 1.8 V 58 (O) 56 (G/B) Mass air flow sensor Input [Engine is running] 0.9 - 1.2 V [Engine is running] 1.6 - 1.9 V 59 (G/W) 64 (B/R) Sensor power supply — [Ignition switch: ON] 5 V 60 (Y/B) — Sensor ground — — — 61 (B) 67 (—) Knock sensor (bank 1) Input [Engine is running] 2.5 V* 1 62 (W) 67 (—) Knock sensor (bank 2) Input [Engine is running] 2.5 V* 1 63 (R/W) 68 (Y/G) Sensor power supply — [Ignition switch: ON] 5 V 64 (B/R) — Sensor ground — — — Terminal No. Description Condition Value (Approx.) + -– Signal name Input/ Output |
