DEF-44 < ECU DIAGNOSIS INFORMATION > BCM (BODY CONTROL MODULE) 76 (V) Ground Driver door antenna Output When the driver When Intelligent Key is in When Intelligent Key is not 77 (P) Ground Driver door antenna Output When the driver When Intelligent Key is in When Intelligent Key is not 80 (SB) Ground NATS antenna amp. Input/ Output During waiting Ignition switch is pressed Just after pressing ignition switch. Pointer of tester should move. 81 (O) Ground NATS antenna amp. Input/ Output During waiting Ignition switch is pressed Just after pressing ignition switch. Pointer of tester should move. 82 (BR) Ground Ignition relay [fuse Output Ignition switch OFF or ACC 0 V ON Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB |
