DOES NOT RETURN BUT MALFUNCTION DETECTION BUZZER SOUNDS SE-79 < SYMPTOM DIAGNOSIS > C D E F G H I K L M A B SE N O P DOES NOT RETURN BUT MALFUNCTION DETECTION BUZZER LH LH : Diagnosis Procedure INFOID:0000000009718754 1. CHECK PRIMARY POSITION LIMIT SWITCH (LH) Check primary position limit switch (LH). SE-22, "LH : Component Function Check" Is the inspection result normal? YES >> GO TO 2. NO >> Repair or replace the malfunctioning parts. 2. CHECK MOTOR SENSOR (LH) Check motor sensor (LH). SE-30, "LH : Component Function Check" Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace the malfunctioning parts. 3. CONFIRM THE OPERATION Confirm the operation again. YES >> Check intermittent incident. Refer to GI-44, "Intermittent Incident" . NO >> GO TO 1. RH RH : Diagnosis Procedure INFOID:0000000009718755 1. CHECK PRIMARY POSITION LIMIT SWITCH (RH) Check primary position limit switch (RH). SE-23, "RH : Component Function Check" . Is the inspection result normal? YES >> GO TO 2. NO >> Repair or replace the malfunctioning parts. 2. CHECK MOTOR SENSOR (RH) Check motor sensor (RH). SE-32, "RH : Component Function Check" . Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace the malfunctioning parts. 3. CONFIRM THE OPERATION Confirm the operation again. Is the inspection result normal? YES >> Check intermittent incident. Refer to GI-44, "Intermittent Incident" . NO >> GO TO 1. |
