DTC P0335 CKP SENSOR EC-185 [YD (WITH EURO-OBD)] C D E F G H I J K L M A EC Diagnostic Procedure EBS013NW 1. CHECK GROUND CONNECTIONS 1. Turn ignition switch OFF. 2. Loosen and retighten engine ground screws. Refer to . OK or NG OK >> GO TO 2. NG >> Repair or replace ground connections. 2. CHECK CKP SENSOR POWER SUPPLY CIRCUIT 1. Disconnect crankshaft position sensor harness connector. 2. Turn ignition switch ON. 3. Check voltage between CKP sensor terminal 1 and ground with OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors. 3. CHECK CKP SENSOR GROUND CIRCUIT FOR OPEN AND SHORT 1. Turn ignition switch OFF. 2. Disconnect ECM harness connector. 3. Check harness continuity between ECM terminal 65 and CKP sensor terminal 2. 4. Also check harness for and short to ground and short to power. OK or NG OK >> GO TO 4. NG >> Repair open circuit or short to ground or short to power in harness or connectors. MBIB0915E MBIB0863E Voltage: Approximately 5.3V PBIB0405E Continuity should exist. |
