AUDIO AV-27 C D E F G H I J L M A B AV Terminal No. (wire color) Item Signal input/ output Condition Voltage Example of symptom ( + ) ( – ) Ignition switch Operation 1(Y/R) Ground Illumination Input OFF Lighting Battery voltage Audio unit illumination Turn lighting Approx. 3.0V or less 2(P) Ground ACC power Input ACC - Battery voltage Audio unit operation is 3(Y) Ground Battery power Input OFF - Battery voltage Audio unit operation is 4(Y) Ground Battery power Input OFF - Battery voltage Audio unit operation is 6(L) 5(LG) Speaker out- Output ON Receive No sound from front LH 8(BR) 7(BR/ W) Speaker out- Output ON Receive No sound from front 10(LG) 9(B/Y) Speaker out- Output ON Receive No sound from rear LH 12(L) 11(P) Speaker out- Output ON Receive No sound from rear RH 14 (W) 13 (B) CD sound sig- Input ON Play CD. CD sound is not heard SKIA0177E SKIA0177E SKIA0177E SKIA0177E SKIA0195E |
