Nissan Tiida C11. Manual - part 904
HAC-280
< ECU DIAGNOSIS >
[AUTO AIR CONDITIONER (W/NAVI)]
AIR CONDITIONER CONTROL
16
GR
Illumination signal
ON
Light switch: ON
Approx. 12
18
O
Power supply for IGN 1
ON
-
Battery voltage
19
LG
Power supply for BAT
OFF
-
Battery voltage
20
B
Ground
ON
-
Approx. 0
21
GR
Blower PWM
ON
FAN speed: 1st step (manual)
22
P
FAN ON signal
ON
FAN speed: 1st step (manual)
23
O
Compressor ON signal
ON
A/C switch: ON
(Blower motor operates.)
24
W
Rear window defogger ON
signal
ON
When rear window defogger
switch is depressed.
Approx. 0
When rear window defogger
switch is released.
Approx. 5
25
BR
Air mix door motor drive sig-
nal
ON
Immediately after temperature
adjustment dial operation.
26
G
27
LG
28
R
30
V
PTC ON/OFF signal
ON
Blower fan: ON
Approx. 0
Blower fan: OFF
Approx. 5
31
G
Intake door motor drive signal
ON
Intake
switch
REC
→
FRE
Approx. 0
FRE
→
REC
Approx. 12
32
V
Intake door motor drive signal
ON
Intake
switch
REC
→
FRE
Approx. 12
FRE
→
REC
Approx. 0
33
GR
Mode door motor drive signal
ON
Immediately after mode control
dial operation.
34
W
35
Y
36
V
Terminal
No.
Wire
color
Item
Ignition
switch
Condition
Voltage
(V)
